200AH Slimline Lithium battery + Redarc 40amp DCDC + 1500W Inverter + Control Panel +

PRO WIRING KIT SKU:(200AHSLIMPACK)

PACKAGE INCLUDES:

1 x POWERTECH 200AH SLIMLINE LITHIUM BATTERY

1 x REDARC 12V 40AMP BCDC CHARGER

1 x POWERTECH 1500W 12v to 240v Pure Sine Wave Inverter

1 x 5gang flush mount Control panel

5 x metres of 8B&S twin core cable

1 x blue 50amp Anderson Plug

1 x Grey 50amp Anderson Plug

1 x Yellow 50amp Anderson Plug (Use for solar input)

4 x 40amp Midi Fuses

4 x midi fuse holders

2 x battery lugs

12.8V 200Ah Lithium Slimline Deep Cycle Battery with Metal Case

This battery comes in a sturdy mild steel black powder-coated case with mounting flanges. Identical to our 100Ah version SB2220 but double the amperage rating. It measures a semi-compact 850 long x 270w (excluding flanges) x 70h.  It has a strong metal handle on the long side above the battery display.  Including a steel box, it weighs 26kgs – quite light for a 200 A/hr battery.  On the end of one long side are 2 x flush mount 50A High Current sockets and on the other side there is 1 x flush mount 120A High Current Socket.  On the top of the case is a battery capacity voltage display that measures 60x40mm (backlit.)

Because of the low profile of this unit, it will fit neatly behind the driver/passenger seat in a car 4WD/RV. The Anderson connectors guarantee a neat wiring installation with no exposed electrical terminals.  It could easily fit somewhere behind the back seat, in a box-type camping trailer or even a small boat under a seat.

REDARC 12V 40AMP BCBC CHARGER

Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.

The BCDC1240D also comes with patented charging profiles, including a lithium charging profile perfect for pairing with a lithium battery The 'Dual' input range will continue to charge all other types of batteries including AGM, GEL, standard lead acid and calcium.

As a guide the BCDC1240D is typically used for lead acid battery banks over 200Ah and lithium batteries over 100Ah.

Features

• Separate DC and solar charging inputs
• Maximises the performance and life of your auxiliary battery
• Simultaneous DC and solar charging with Green Power Priority
• Suits 12V/24V standard and variable voltage/smart alternators
• Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO₄) batteries
• Suitable for use on vehicles with conventional alternator charging systems

1500W 12VDC to 240VAC Pure Sine Wave Inverter - Electrically Isolated

This pure sine wave inverter is suitable for mobile or permanent power installations. It is capable of providing 1,500W continuously and a 3,000W surge. Ideal for powering microwaves, power tools, TVs, and other power thirsty devices when you are away from mains power. It features a standard 240VAC mains outlet as well as a USB port (2.1A) to charge USB devices. To avoid your 12V battery going flat, a low voltage alarm will alert you when the battery voltage reaches 10.5V, and then shutdown the inverter when the battery reaches 10V. All of the safety features you expect, short circuit protection, overload, low/over voltage, and over temperature. Two built-in cooling fans automatically run when the inverter gets too hot so you can run it for longer in hot conditions. Supplied with heavy duty DC leads and remote control kit.

Features:
• 1500W AC Output
• 3000W max power start for 10 seconds
• Greater than 90% Efficiency
• Low voltage alarm and shutoff
• USB port to charge USB devices

5 Gang ON-OFF Toggle Switch Control Panel

Newest 5 Blue LED Toggle Switches with Overload, Over-current and Short Circuit Protection.
Sleek & Contemporary design, high quality aluminium , perfect for your machine.
Easy to install, can be installed horizontally or vertically (Horizontally optional)
Stainless Steel Screw and labels included, suitable for both 12V and 24V systems Panel is pre-wired.

Features

Switch Panel
Material ：ABS, Aluminium Plate
Installation:Pre-wired
Switches Available: 5 Gang (LED LIGHT BAR, SPOT LIGHTS, SIDE LIGHTS, ROOF LIGHTS, ZOMBIE LIGHTS, DRIVING LIGHTS)
Amp Rating per circuit:15amp Max
Rocker Switch:5
Loop Circuit:ON-OFF
Switch System: Water-resistant enclosed Rocker switch
Overload protection: 12V - 24V, 15A DC
USB socket output: DC 5V / 4.2A(total)
Operating Temperature: -25 degree to 80 degree
Electrical Life:10000 make and break cycles at full load
IP Rating:IP67
